Dimension |
:
|
130mm x 67mm (4.5” x 2.6” x 1.6”) |
|
Weight |
: |
450 gms. (With Batteries) |
|
Accessories |
:
|
Standard:
- Carring Case Batt. Charger
Optional: - Aspirator adaptor |
|
Measurement
Range |
: |
0 – 50 ppm |
|
Display |
: |
Liquid
Crystal Display (LCD) |
|
Standard
Alarm Levels |
: |
At TLV |
|
Optional
Alarm Levels |
:
|
As
per specification |
|
Alarm
Indication |
:
|
Pulsating / Continuous red LED with audible, 90 db at 1 Meter |
|
Battery |
: |
Standard:
Rechargeable 4 x AA cells
Optional: Disposable |
|
Battery
Life |
: |
12 – 15 hrs. Continuous |
|
Oper.
Temperature |
: |
-10
deg C to 50 deg C. (14 deg F
to 122 deg F) |
|
Humidity |
: |
0
– 95% RH Non - Condensing |
| Accuracy |
|
+/- 10 of Test Gas Concentration |
|
Resolution |
: |
1ppm |
|
Response
Time |
: |
T90 < 60 Sec. |
|
Setting |
: |
Zero/ Span accessible from outside |
|
Sensor
Type |
: |
Electrochemical |
|
Sensor
Life |
: |
Max. 2 years (in fresh air) |
Tested for Intrinsically safe as per IS 5780-2002{IEC-60079-11(1999)}
